Description
Difference and Common mode DC Surge arrester for Photovoltaic protection against surges at the boundaries from lightning protection zone 0B-1 and higher.
- DIN rail mountable and ease of installation
- Two part design consisting of base and plug-in protection module
- Differential and common protection mode
- High energy MOV (Metal Oxide Varistor) inside
- Short circuit current rating(SCCR) 200kA without external fuse or CB
- Reliable supervision due to disconnection device
- Fault indication by red indication flag in window
- Fast response
- ETL approval in accordance with UL 1449 3rd Edition
- With remote alarm terminal optional
Extra Information
Brand:
DynaShield®
